Rig Fleet Onshore



Mast Height ---------------------- Clear height -148ft
Hook Load Capacity ----------- 700,000 Lb with 12 lines
Crown Block --------------------- Lanzhou TC315-6, 700,000 Lb, Drill line size 1-3/8” RigSubstructure ---------------- Floor Height -30 Ft, Under Rotary Beams - 26 Ft Set backcapacity --------------------- 350,000 Lbs + 700,000 Lbs
Hook & Block Assembly --------- Lanzhou DG315, YC315, 700,000 Lb Capacity
Rotary Table --------------------- Lanzhou ZP275, 27 ½”
Draw works ---------------------- Lanzhou JC50D, 1500 HP, 1 3/8” Grooved drum,
Max 76,000 Lb Fast-line Pull, 487,000 Lb Max Capacity
Brakes Mechanism ------------ Drum brakes & Electric auxiliary – Lanzhou DS-45
Mud Pump ------------------------ Lanzhou, Model 3NB1300C, 1300 HP, Belt-driven, Dual 752 Traction Motors


Rig Fleet Offshore

Length (molded) .................................................................................... 234' (71.3 m)
Breadth (molded) .................................................................................. 208' (63.4 m)
Hull Depth ................................................................................................. 25' (7.6 m)
Leg Length ............................................................................................. 430’ (111 m)
Usable Leg Length (below hull) .......................................................... 372' (113.3 m)
Spud Can Area .................................................................. 1643 sq. ft. (152.6 sq. m)
Spud Can Diameter ....................................................................... 47 ft. (14.3 sq. m)
Drilling Envelope ........................................................ 50’ aft and 15' from centre line
Gross tonnage ........................................................................................... 9264 tons
Helideck size/rating ............................................................ 73' /for a Sikorsky S-61N


Drill stem Testing Drillstem Testing (DST) is a valuable tool in the oil and natural gas extraction process. DST is a process to establish the productive capacity, pressure, permeability or extent of an oil or gas reservoir. Drill stem testing is basically a flow test, which is performed on isolated formations of interest to determine the fluids present and the rate at which they can be formed.
